FEATURES
Ï Designed for measuring AC current, AC voltage resistance and DC
voltage .
Ï Rotary scale which presents only one scale in windows at one time
to avoid any possible reading errors.
Ï Pointer lock function freezes the reading in dimly lit or hard to reach
places.
Ï © range ideal for checking the continuity or relays, transformers and
motor coils.
SPECIFICATIONS
AC A : 6 / 15 / 60 / 150 / 300A
± 3% of F.S.( 50/ 60Hz)
AC V : 300 / 600V
± 3% of F.S.
DC V : 75V
± 3% of F.S.
© : 2k©
Frequency
response : 50 / 60Hz for ACA 6A
50-400Hz for ACA
15 / 60 / 150 / 300A
Dimensions : 230( L) × 72( W) × 37( D) mm
Conductor size : 38mm Max.
Weight
( battery Included) : Approx. 420g
Safety standard : EN 61010-1 CAT II 600V
EN 61010-2-32
