FEATURES
Ï 3½ digit liquid crystal display with maximum reading of 1999.
Ï Over range indication : " 1 " is displayed on highest digit.
Ï Low battery indication: " B " sign appears on the display.
Ï Response time: approx. 1 second.
Ï Data hold: for all ranges

SPECIFICATIONS

AC A 200 / 1500A
± ( 2.0% rdg+ 4dgt)
( 40Hz-1kHz)
AC V 200 / 750V
± ( 1.5% rdg+ 2dgt)
( 40Hz-1kHz)
& 200&
± ( 1.5% rdg+ 2dgt)
Buzzer Resistance is less then 30&
Peak hold Ç
Conductor size 55mm Max.
Operating
temperature 0º C ~ 40º C
Humidity 85%
Current
consumption Approx. 10mA
Dimensions 245( L) × 70( W) × 41.7( D) mm
Weight
( battery Included) Approx. 480g
Power source 9V( 6F22) × 1
