| FEATURES |
● 2000 counts.
● DC Voltage measurement.
● 4-wire resistance measurement.
● Data hold function.
● Low battery indication.
● 9V DC power supply.
● Measure battery types: Li-ion, Ni-Cd, Ni-MH
● Simple operation.
● Lead resistance and contact resistance eliminated. |
| |
| SPECIFICATIONS |
| |
|
|
| DC Voltage |
|
|
|
| Range |
2V
|
20V
|
100V
|
| Resolution |
1mV
|
10mV
|
100mV
|
| Accuracy |
±(1%rdg+1dgt)
|
±(1%rdg+1dgt)
|
±(1%rdg+1dgt)
|
| Resistance |
|
|
|
| Range |
200mΩ
|
2000mΩ
|
20Ω
|
| Resolution |
0.1mΩ
|
1mΩ
|
10mΩ
|
| Accuracy |
±(3%rdg+3dgt)
|
±(3%rdg+3dgt)
|
±(3%rdg+3 dgt)
|
| General |
|
|
|
Low battery
indication |
"  " sign appears on the display when the battery voltage drops
below accurate operating level. |
| Dimensions |
192(L) × 88.6(W) × 45.2(D)mm |
Weight
(battery included) |
Approx. 360g |
| Power source |
9V(6F22) × 1 |
| Safety standard |
EN 61010-1 CAT I 100V
EN 61326-1
|
|
|
|
|
= = = = = = = = = = = = = = = = = = = = = = = = = = = = =
