FEATURES
Ï Full auto range for V.A and © functions.
Ï Data hold function freezes the reading in dimly lit or hard to reach
places.
Ï Low battery indication.
Ï Built-in buzzer for continuity test.
Ï Safety design throughout with no exposed metal parts. Shielded
banana plugs and recessed input terminals.
Ï Ohm function ideal for checking continuity of relays transformers
and motor coils.

SPECIFICATIONS

AC A 400A / 1000A
± ( 1.5% rdg+ 3dgt) : 40-500Hz
AC V 400V / 600V
± ( 1.0% rdg+ 3dgt) : 40-500Hz
DC A 400A / 1000A
± ( 1.5% rdg+ 3dgt)
DC V 400V / 600V
± ( 0.75% rdg+ 3dgt)
& 400& / 2000&
± ( 1.0% rdg+ 3dgt)
Flashlight
LCD backlight display
Buzzer sounds < 38&
Conductor size 40mm Max.
Low battery
Indication
Dimensions 255( L) × 80( W) × 35( D) mm
Weight
( battery included) Approx. 420g
Power source 9V( 6F22) × 1
Safety standard EN 61010-1 CAT III 600V
EN 61010-2-32
