FEATURES :

True measurement of speaker systems actual impedance at 1kHz.
Three test ranges ( 20© / 200© / 2000© ) allow testing of home
theater and commercial sound systems.
Measures transformer impedances.
Battery operated.
Low battery indication.
Data hold function.
Timer function for continuous hands free operation.
The timer can last about 3-5 minutes when users press.
TEST ON/ OFF button.

SPECIFICATIONS

Measuring ranges : 0-20 / 0-200 / 0-2000©
Test frequency : 1kHz
Accuracy : 20© : ± 2% rdg ± 2dgt or ± 0.1© ,
which is greater
200© / 2000© : ± 2% rdg ± 2dgt
Low battery
indiction : “ " Symbol appears on
the display
Data hold indiction : “ “ Symbol appears on
the display
Display : LCD 3½ digit ( 2000 counts)
Dimensions : 205( L) × 90( W) × 55( D) mm
Weight
( battery included) : Approx. 530g
Power source : 1.5V( AA) × 6
Safety standard : EN 61010-1 CAT III 270V
EN 61326-1
