FEATURES :

High quality Taut Band movement.
Battery operated.
Timer function for hands free use.
Battery indicator.
The tester measure with a frequency of 1kHz.
Measure speaker’ s impedance.
Measure speaker lines ( connected to load) .
Help to calculate and check audio power systems.
Ideal for public address installation and maintenance.
Measure transformer impedances.

SPECIFICATIONS

Measuring system : Constant current inverter
with 1kHz approx. 2mA
Measuring ranges : 20© / 200© / 2k©
Accuracy : ± 2.5% of full scale
Dimensions : 163( L) × 100( W) × 50( D) mm
Weight
( battery included) : Approx. 420g
Power source : 1.5V( AA) × 6
Safety standard : EN 61010 CAT II 100V.
