FEATURES
Ï Rotary scale which presents only one scale in windows at one time
to avoid any possible reading errors.
Ï Pointer lock function freezes the reading in dimly lit or hard to reach
places.
Ï © range ideal for checking the continuity or relays, transformers and
motor coils.
Ï TAUT BAND movement.

SPECIFICATIONS

AC A 10 / 30 / 100 / 300 / 1000A
± 3% of F.S.( 50/ 60Hz)
AC V 150 / 300 / 750V
± 3% of F.S.
DC V
& 2k&
± 3% of Scale length
Frequency
response 50 / 60Hz for ACA 10A
50-400Hz for ACA
30 / 100 / 300 / 1000A
Dimensions 227( L) × 73( W) × 33( D) mm
Conductor size 52mm Max.
Weight
( battery Included) Approx. 460g
