Features:
- Works with compressed plant air
- 0.001 psi resolution, 0.035% accuracy
- Dual digital display – psi & mA or voltage
- Gauge, differential, and vacuum modes
- Selectable engineering units
- Pressure switch test
- Rugged case to withstand factory floor environment
Specifications
| Accuracy | ||
| Pressure: ±0.035% FS mA: ±0.025% FS Volts: ±0.025% FS |
||
| Temperature Coefficient | ||
| ±0.01% FS per °C; 0°C to 18°C, and 28°C to 50°C |
||
| Loop Power | ||
| 24VDC, current limited to a nominal 24 mA | ||
| Switch Test | ||
| Dry (unpowered) contacts only, nominal 24 mA @ 24 VDC excitation current supplied to contact | ||
| Modes of Operation | ||
| Gauge, Differential, (Vacuum to -5 PSI) | ||
| Standard Engineering Units | ||
| PSI, Bar, mmHg, kPa | ||
| inH2O @ 4°C, 20°C, 60°F cmH2O @ 4°C, 20°C mmH2O @ 4°C, 20°C |
||
| mBAR, kg/cm2 | ||
| Media Compatibility | ||
| Clean, non-corrosive air or gas | ||
| Environmental | ||
| Operating Temperature | -10 °C to +55 °C (32 °F to 122 °F) |
|
| Storage | -20 °C to +60 °C (-4 °F to +154 °F) | |
| Mechanical | ||
| Dimensions | 13.5" H x 11.5"W x 5.5"D 343mm x 292mm x 140mm |
|
| Input Port(s) | 1/8" female NPT | |
| Power | ||
| Battery | one Ni-CD battery or AC adapter that simultaneously charges and power calibrator | |
| Electrical Protection | Fuse, 1/8 Amp | |
