• DC voltage range is also available especially for checking emergency battery operated power supply.
• Can measure temperature using optional probe.
• Tear drop shaped transformer jaws for ease of use.

AC A 6/ 15/ 60/ 150/ 300A ± 3% of FS
AC V 150/ 300/ 600V ± 3% of FS
DC V 60V ± 3% of FS
© 1/ 10k© ( 25/ 250© mid-scale)
| ± 2% of scale length
Temperature -20º C~ + 150º C ( with the use of Temperature Probe 7060)
| ± 5º C ( 0º C~ + 100º C)
| ± 10º C ( other ranges)
Conductor Size Ø 33mm max.
Frequency Response 50Hz/ 60Hz
Safety Standard IEC 61010-1 CAT.III 300V Pollution Degree 2
IEC 61010-2-031
IEC 61010-2-032
Withstand Voltage 3700V AC for 1 minute
Power Source R6P ( AA) ( 1.5V) × 1
Dimensions 193( L) × 78( W) × 39( D) mm
Weight 275g approx.
Accessories 7066A ( Test leads)
8923 ( Fuse [ 0.5A/ 600V] ) × 2
9097 ( Carrying case)
R6P ( AA) × 1
Instruction Manual
Optional 7060 ( Temperature probe)
8008 ( Multi-Tran)

================================

Untuk Informasi dan Pemesanan Hubungi:

DARMATEK

Contact Person : ubarkah

Telp/ Fax : 021-71031268/ 021-78890541

HP : 081283804273/ 085774067221

Email : subarkah18@ yahoo.co.id

Gmail : darmatek1@ gmail.com

Y M : cs_darmatek

Pin BB : 7512CBB7

Web : www.darmatek.com
