DESCRIPTION
The CD100A is designed to detect combustible gas leaks in residential and small commercial applications.
It is small, easy to use and has a 18" long flexible gooseneck for hard to reach areas.
Simple adjustable tick rate increases as the sensor tip approaches a leak
Audio and visual tick rate, fully adjustable
Easy one hand operation
Long 18" (45cm) gooseneck for hard to reach areas
'Tip Light' in sensor cover illuminates the area of the leak
Rubber boot protects instrument
Sensor provides accurate detection
Headphone jack
Separate battery compartment for quick and easy battery replacement
Partial list of gases sensed:
Acetone, Alcohol, Ammonia, Benzene, Butane, Gasoline, Halon, Hydrogen Sulfide, Industrial Solvents, Jet Fuel, Laquer Thinners, Methane, Naphta, Natural
Gas, Propane, Refrigerants, Toluene... and more.
SPECIFICATIONS
| Power Supply | 9V Alkaline battery |
| Battery life | 5 hours typical use |
| Sensor | Solid state semiconductor |
| Sensitivity | 50ppm |
| Dimensions | 8" x 4" x 1.5" (200 x 100 x 38mm) |
| Gooseneck | 18" (450mm) |
| Tick adjustment | Fully adjustable thumbwheel |
| Tick indication | Flashing LED |
=======================
