Imaging Performance
Detector Type Uncooled FPA Microbolometer
( 160 x 120 pixels)
Spectral Range 8 to 14 µ m
Field of View 30º x 22.5º
Focus Fix focus
Thermal Sensitivity 0.1º C ( 100mK) at 30º C
Image Presentation
External Display 3.5 " high resolution color LCD ( TFT)
Video Output Built-in digital camera 640 x 480 pixels
Measurement
Temperature Range -20 to 500º C ( -4 to 932º C)
Accuracy ± 2.0% or ± 2º C whichever is greater
Emissivity Fix emissivity
Measurement method
Fix point
Palette Fire fighting palette
Environmental Conditions
Operating Temperature 80º C up to 30 minutes

120º C up to 10 minutes

260º C up to 5 minutes
Storage Temperature -40 to 70º C ( -40 to 158º F)
Encapsulation IP67
Power System
Battery Type Rechargeable Li-ion camcoder battery, field replaceable
Charging System Built-in or with external battery charger
Battery Operating Time Over 2.5 hours continuous operation
External Power AC Adapter 110/ 220VAC, 50/ 60Hz
Physical Characteristics
Weight < 1.3kg ( without battery)
Size 273x190x128mm

= = = = = = = = = = = = = = = = = = = = = = = =
