Imaging Performance:
Detector Type Uncooled FPA Microbolometer ( 384 x 288 pixels, 25 µ m)
Spatial Resolution 1.2 mrad
Spectral Range 8 to 14 µ m
Field of View 14º x 10º
Image Frequency 50 Hz PAL / 60 Hz full real time
Thermal Sensitivity 0.08º C ( 80mK) at 30º C
Electronic Zoom x2, x4, x8
Laser Sighting Class II, semiconductor diode laser 1 mW / 635 nm
Image Presentation
External Display 4 " high resolution color LCD ( TFT)
View Finder 0.25 " built-in high resolution color LCD ( TFT)
Video Output:
PAL / NTSC composite video
Measurement
Temperature Range -20º C to 500º C ( up to 1500º C optional)
Accuracy ± 2.0º C or ± 2% of reading
Measurement Modes Spot / Manual ( up to 4 moveable) • Spot / Automatic
placement at maximum • Area ( up to 4 moveable)
displaying either max, min, or average • Isotherm •
Line Profile • Alarm
Emissivity Adjustable from 0.01 to 0.99 by 0.01 increments
Image Storage Type Removable Compact Flash Memory Card
Voice Annotation 60 seconds of digital voice clip per file
Power System
Battery Type Rechargeable Li-ion Camcoder battery,
field-replaceable
External Power
Operation AC Adapter 110/ 220 VAC, 50/ 60 Hz
Environmental Specifications
Operating Temperature -20º C to 60º C
Storage Temperature -20º C to 60º C
Humidity Operating and storing up to 95% , non-condensing
Encapsulation IP54 IEC 529 housing
Physical Characteristics
Weight 1.6 kg ( including battery)
Size 148 x 104 x 108 mm ( camera only)
Tripod Mounting 1/ 4 " - 20
