Imaging Performance:
Detector Type Uncooled FPA Microbolometer ( 320 x 240 pixels, 45 µ m)
Spatial Resolution 1.2 m RAD
Spectral Range 8 to 14 µ m
Field of View 21º x 15º
Image Frequency 50 Hz PAL / 60 Hz NTSC, non-interlaced
Thermal Sensitivity 0.08º C ( 80mK) at 30º C
Electronic Zoom x2, x4 interpolating
Laser Sighting Single point, Class II, up to 1 mW
Image Presentation
External Display 4 " high resolution color LCD ( TFT)
View Finder 0.25 " built-in high resolution color LCD ( TFT)
Video Output PAL / NTSC, composite video ( built-in Digital Camera
640 x 480 pixels)
Measurement
Temperature Range -20º C to 500º C ( up to 1500º C optional)
Accuracy ± 1.0º C or ± 1% of reading
Measurement Modes Spot / Manual ( up to 4 moveable) • Spot / Automatic
placement at maximum • Area ( up to 4 moveable)
displaying either max, min, or average • Isotherm •
Line Profile • Auto alarm
Emissivity Adjustable from 0.01 to 1.0
Image Storage Type Compact Flash Card
File Format IMG ( an individual file consists of infrafed image
and voice annotation if any)
Voice Annotation 8 seconds of digital voice clip per file
Power System
Battery Type Rechargeable Li-ion Camcoder battery,
field-replaceable
External Power
Operation AC Adapter 110/ 220 VAC, 50/ 60 Hz
Environmental Specifications
Operating Temperature -20º C to 60º C
Storage Temperature -20º C to 60º C
Humidity Operating and storing 10% to 95% , non-condensing
Encapsulation IP54 IEC 529 housing
Shock Operational 25 G, IEC 68-2-29
Vibration Operational 2 G, IEC 68-2-6
Interfaces
Remote Control RS232 serial communication
Live Video Tranmission Up to 750 m to remote monitor
( optional)
Physical Characteristics
Weight 1.5 Kg ( including battery)
Size 148 x 104 x 108 mm ( Standard Model)
Tripod Mounting 1/ 4 " - 20
