Application :
- Cement Klin
- Tobacco Industry
- Flat Glass Manufacturing ( Annealing Process)
- Metallurgy Industry
- Computer Board Industry
- Food Processing Industry
- Material Handling
Imaging Performance
Field Of View
18° Horizontal x 13° Vertical
Lens
13mm
Spatial Resolution
1.3mrad
Optical Resolution
500 : 1
Thermal Sensitivity / NETD
100mK / 0.1° C at 30° C
Image Frame Rate
50Hz / 60Hz full real time
Focus
Manual adjust, 30cm ( 11.8 " ) to infinity
Detector
160 x 120, Uncooled Microbolometer FPA ( Ulis France)
Spectral Range
8 ~ 14µ m
Measurement
Temperature Range
-20 to 350° C ( -4 to 482° F) , optional up to 600° C
Accuracy
± 2° C or ± 2%
Measurement Modes
Four moveable spot, three moveable area displaying max/ min/ avg, line profile, isothermal band, temperature difference, color alarm
Display Color
11 palettes
Image Adjust
Auto / Manual
Setup Functions
Measurement setting, measurement correction, analysis, date & time, local adapt, system information, factory default, network setting
Emissivity Correction
0.10 to 1.00 by 0.01 increments
Environment Temperature Correction
Automatic corrections based on user input
Atmospheric Transmission
Automatic corrections based on user input for ambient temperature, distance, and relative humidity
Image Storage
File Format
Single photo capture in BMP, Streaming video in MPEG-4
Image Capture
Single frame raw image manual captured via control software, the captured images are analyzable and temperature measurable
Interface
Analog Video Output
PAL/ NTSC
Digital Video Output
RJ-45 Ethernet output, MPEG-4 digital video/ raw temperature measured data
Output
General purpose output
Network Interface
RJ-45 Ethernet output for thermal image, data transfer, and camera control
Power Source
External Power Source
12VDC, 550mA
Power Consumption
< 6 Watt
Enviromental
Operating / Storage Temperature
-15 to 50° C ( -5 to 122° F) / -40 to 70° C ( -40 to 158° F)
Operating / Storage Humidity
< 90% , non condensing
Enclosure
IP40
Physical Characteristic
Unit Dimensions
224 x 92 x 82mm
Unit Weight
800g ( without lens)
Tripod Mounting
¼ " - 20
Accessories
Standard Accessories
IR Camera with lens • CD Software • Power Cable • Video Cable • 2m Network Cable • Instruction Manual • Carrying Case & Strap • Warranty Card • Certificate of Product Conformance
Optinoal Accessory
High temperature lens 600° C
