Keterangan :

Rated input current 5000 A AC 500 A AC
Max. allowable input Continuous 10000 A ( at 45 to 66 Hz, requires derating at frequency)
Output voltage 500 mV AC/ f.s. ( AC 0.1 mV/ A) 500 mV AC/ f.s. ( AC 0.1 mV/ A)
Amplitude accuracy ± 2 % rdg. ± 0.3 % f.s. ( at 45 to 66 Hz, center of sensor)
Phase accuracy ± 1° ( at 45 to 66 Hz)
Bandwidth 10 Hz to 20 kHz ( ± 3dB)
Max. rated voltage to earth 1000V ACrms ( CAT III) , 600V ACrms ( CAT IV)
Core diameter Æ 254 mm ( 10 inch)
Power supply LR6 ( AA) alkaline batteries × 2, Continuous use : 7 days ( Rated Power 35 mVA) , or AC adapter 9445-02/ -03 ( Rated Power 0.2 VA) , or External power supply 5 to 15 V DC ( Rated Power 0.2 VA)
Dimensions and mass Sensor thickness: Æ 13 mm, Cable length: Between sensor and battery box: 2 m ( 6.56 ft) , Output cable: 1 m ( 3.28 ft)
Battery box: 35 mm ( 1.38 in) W × 120.5 mm ( 4.74 in) H × 34 mm ( 1.34 in) D, 470 g ( 16.6 oz)
Accessories LR6 ( AA) alkaline batteries × 2, Instruction manual × 1

= = = = = = = = = = = = = = = = = = = = = = = = = = = = = = =
