- 0.1% DC accuracy
- Current measurements up to 10 A, 20 A for up to 30 seconds
- Millisecond pulse width measurements for fuel injectors
- Optional magnetic hanger allows meter to attach to the vehicle and free your hands for other tasks
- Min/Max/Average recording with Min/Max Alert to capture variations automatically
- Peak Min/Max to record transients as fast as 250 μs
- Relative mode to remove test lead resistance from low ohms measurements
- Auto and manual ranging for maximum flexibility
- Autohold™ to capture stable readings with only one touch of the leads
- Large display digits and two-level bright white backlight for increased visibility
- Analog bargraph to track changing or unstable signals
- Input Alert provides audible warning against wrong use of input jacks
- Access door for fast battery changes without opening up the case
- "Classic" design that fits your hand with new removable holster, built-in test lead and probe storage
- 10 meg ohm input impedance won’t damage computer circuits
- Limited lifetime warranty
| Technical Specifications | ||
| DCV | Maximum voltage | 1000 V |
| Accuracy | ±(0.1% + 1) | |
| Best resolution | 0.01 mV | |
| ACV | Maximum voltage | 1000 V |
| Accuracy | ±(0.5% + 2) | |
| AC bandwidth | 5 kHz | |
| Best resolution | 0.01 mV | |
| DC current | Maximum amps | 10 A |
| Amps accuracy | ±(0.4 % + 2) | |
| Best resolution | 0.001 mA | |
| AC current | Maximum amps | 10 A |
| Amps accuracy | ±(1.2% + 2) | |
| Best resolution | 0.001 mA | |
| Resistance | Maximum resistance | 50 MΩ |
| Accuracy | ±(0.4% + 1) | |
| Best resolution | 0.1 Ω | |
| Capacitance | Maximum capacitance | 9,999 µF |
| Accuracy | ±(1% + 2) | |
| Best resolution | 0.01 nF | |
| Frequency | Maximum frequency | 200 KHz |
| Accuracy | ±(0.005% + 1) | |
| Best resolution | 0.01 Hz | |
| Duty cycle | Maximum duty cycle | 99.9% |
| Accuracy | within 2% per KHz + 0.1% | |
| Best resolution | 0.1% | |
| Temperature measurement | -200.0°C – 1090°C -328.0°F – 1994.0°F, 1.0% excluding probe |
|
| 80 BK temperature probe | -40 °C – 260°C -40 °F – 500°F, 2.2°C or 2% whichever is greater |
|
| Conductance | Maximum conductance | 60.00 nS |
| Accuracy | ±(1.0% + 10) | |
| Maximum resolution | 0.01 nS | |
| Operating range | Operating temperature | -20°C – 5 °C |
| Storage temperature | -40°C – 60°C | |
| Physical | 5.2 x 9.8x 20.1 cm (2.06 x 3.86 x 7.93 in) 624 g (22 oz.) |
|
