EXTECH 382068 Clamp On Power Datalogger

The Extech 382068 clamp-on power datalogger kit measures DC and AC True Power, Apparent Power, Power Factor and True RMS Voltage, Current, and Watts. Status indication for Lead/ Lag and PF is included with the Extech 382068 clamp-on power datalogger kit as well as dual displays of KW + PF, KVA + PF, V + A, A + Hz, and V + Hz. The frequency of voltage and current measurements can also be displayed.

Datalogger and RS-232 PC interface features are built into the Extech 382068 clamp-on power datalogger kit. The Datalogger/ Data Acquisition software package is for exclusive use with the Model 382065 clamp on power datalogger. Windows® 95, 98, NT, 2000, ME and XP operating systems are supported. Users can download readings stored in the Extech 382068 clamp-on power datalogger kit to a PC, program sample rates for datalogging, remotely monitor readings, and save readings to ASCII files for export to spreadsheet and other programs.

The Extech 382068 clamp-on power datalogger kit ships complete with RS-232 module, Windows® compatible software, cable, 9V battery, alligator clips, test leads, and carrying case.

Features:
1000A clamp measures 1f or 3f ( phase) power to 600kW
Display true power, apparent power, power factor, true RMS voltage and current, resistance and frequency
Dual display of kW + PF, kVA + PF, V+ A, A+ Hz or V+ Hz
Clamp jaws open to 1.8 " ( 46mm)
Built-in recorder datalogs up to 4000 readings or download to a PC
25 point data memory viewable on the LCD display
Full function display on large 4-digit LCD with fast 40 segment bar graph, Peak Hold and MIN/ MAX
RS-232 module with PC software to capture and display data

==============================================
