Overview
BrACaudit KY-8000 is a fuel cell based breath alcohol tester designed and intended for use in various applications. With its UK made electrochemical sensor, KY-8000 provides users accurate and rapid testing performance at a fair price.
BrACaudit KY-8000 is a fuel cell based breath alcohol tester designed and intended for use in various applications. With its UK made electrochemical sensor, KY-8000 provides users accurate and rapid testing performance at a fair price
PRODUCT FEATURES
1 Data Handling Ability: 32-bit embedded processor secures high performance of the system
2 UK made Electrochemical/ Fuel cell sensor: Highly specificity to alcohol, unaffected by other possible breath contaminants.
3 Compact gas circuit design and advance analysis process assure fast, accurate and stable testing performance.
4 Memory Capacity: Data storage of 4000 test results. Any test results can be easily recalled, printed or downloaded to a computer.
5 Both active and passive blowing mode available.
6 Compact, portable and easy to use.
7 Power Supply: Nokia BP-6M rechargeable li-ion battery.
8 Built-in clock IC and an individual battery for the clock always secure correct time.
9 After-sales Service: Independent intellectual property rights integrated with research, development and production ability guarantee strong after-sales service support
Technical Data
Principle of Measurement
Electrochemical Sensor, alcohol- specific
Measurement Range( BrAC)
0.000mg/ L^ 1.500 mg/ L
Resolution
0.0001 mg/ L
Accuracy:
Max. Measure error,
in relation to ethanol standard
Ethanol Vapor Concentration / ( mg/ L)
Deviation
C< 0.400
± 0.020 mg/ L
0.400dC< 1.000
± 5%
Ce1.000
± 20%
Repeatability of Indicating Value
Ethanol Vapor Concentration / ( mg/ L)
Deviation
C< 0.400
0.007 mg/ L
0.400dC< 1.000
1.75
Ce1.000
6
Calibration
Every 6 Months
Temperature Range- Operation
10 ^ 45
Temperature Range - Storage
20 ^ 70
Optimum Storage Condition
Temperature 20 ± 5 Humidity < 80% RH Pressure 86 kpa^ 106 kpa
No vapor or electromagnetic disturbances in the environment are influencing the normal working conditions of the device
Blowing Time
3 seconds breath flow e20L/ min
Display
1.8 inch
Memory Capacity
Stores 4000 measured values with date and time ( data can be downloaded to a PC or printer)
Printer
Micro Thermal Printer
Dimensions ( L x W x T)
Approx.128mm L × 59mm( W) × 26.5mm T
Operation Voltage
State of charging
State of operation
USB port, 5V
DC 3.6V^ 8.4 V
Batteries
1000mAh/ 3.7V Lithium-ion rechargeable battery
Weight
Approx. 142g Including battery
========================================
